LSR manufacturing turn-key solution supplier (LIM)
1 Years
| Ask Lasest Price | |
| Brand Name : | Better |
| Model Number : | Better-1200SD-3RT |
| Certification : | CE、ISO |
| Price : | USD42000-USD82000per set |
| Payment Terms : | D/A,D/P,T/T |
| Supply Ability : | 15 sets per month |
| Delivery Time : | 45 days |
| Specifications: | |
| BETTER 1200SD-3RT Vertical LSR injection molding machine | |
| clamping force | 120tons |
| size | 1290*560mm |
| max mold size | 550*550mm |
| Min mold height | 120mm |
| mold stroke | 280mm |
| max daylight | 400mm |
| ejector force | 3tons |
| Thimble diameter | Φ25 |
| ejector distance(product) | 300mm |
| Max hydraulic pressure | 140kg/cm2 |
| cooling water | 1500-1800liters/hr |
| ElectrothermaL | 4kw |
| Motor | 15kw |
| Dimention (L*W*H) | 2.28*2.6*3.12/3.86 |
| weight | 7.4tons |
Full System:
1. Manual /automatic injection
Precise injection molding and automatic accurate control of injection volume,injection speed,temperature and other mold assembly (convenient for mold dragging)devices.
2.MODERN PRODUCTION WORKSHOP
With the high-precision CNC processing equipment, it ensures the accuracy and appearance of process parts and improves the productivity.So the quality is stable and the products can be customized.
The workshop strictly executes the 6S management and modern management and it has an independent quality control system to ensure quality. Every process shows its originality.
3.OUR TERMINAL AIM
Our company considers the product quality as life of a enterprise. We are committed to building an advanced manufacturing platform; using a high-standard quality management system;improving continuously and pursuing higher product quality. Focus on quality first is our commitment and responsibility to customers.
FULL SYSTEM
A stable and economic production process largely depends on the quality of the process components. Equally important and often underestimated is the importance of coordination of the individual components to one another.
As a full system supplier, BETTER develops and manufactures all relevant elements for a LIM production cell in China in compliance with the strictest quality guidelines. Through years of experience BETTER is specialized in integrating its own product range with the appropriate injection molding machine and other automation components into a complete cell.
The customer specifies the part geometry and tolerances, the annual production volume and any further requirements. In a fixed-price offer BETTER presents the turnkey solution including all required components, as well as an extensive acceptance procedure and all necessary training.
This makes BETTER to your specialist and leading partner for high grade Turnkey Solutions for LSR (liquid silicone rubber) injection molding worldwide!
Typical Features and Options:
1,LSR Injection Unit (Special barrel and LSR screw with static seal)
2,Closed loop liquid barrel cooling
3,Pin-type shut-off nozzle (Pneumatic or hydraulic actuation)
4,LSR nozzle tip with static seal
5,LSR tip assembly and non-return valve (Optional spring-lock positive shut-off design)
6,Carriage decompression control
7,Integral mold temperature control system
8,Insulated platens
9,LSR closed loop process software package for precise volumetric control
10,Mould vacuum system (Vacuum pump, vacuum switch, interface, control software)
11,Mould sweep software and sweep device interface
12,Mould cold deck valve gate control system
13,Air blow with pressure regulation
14,Pre-dosing assembly with two component temperature controlled static mixer and purge valve
15,LSR material delivery system
|
|
